AGM Asp-Micro TM160 Short Range Thermal Imaging Monocular 160X120 (50 Hz)

The Asp-Micro handheld observational thermal monocular is equipped with a 160120 infrared detector and a 720540 LCOS display. It supports functions of observation, highest temperature target tracking, distance measurement, Wi-Fi hotspot, and so on. The high-sensitivity built-in thermal detector provides you with clear view even in total darkness. The monocular is mainly applied to scenarios such as patrolling, law enforcement, searching and rescuing, drug enforcement, antismuggling, criminal seizing, hiking, travel, and hunting, etc.

• Model No : 3093251001AM10
• UPC : 810027774491
• Brand : AGM Global Vision
• AGM Asp-Micro TM160 Short Range Thermal Imaging Monocular 160x120 (50 Hz)
• 160120 or 384288 resolution, high sensitivity detector
• Adaptive AGC, DDE, 3D DNR
• 720540 resolution LCOS display
• Built-in rechargeable Lithium battery
• More than 7 hours continuous running (with Wi-Fi hotspot function off)
• Wi-Fi hotspot
• Type-C interface
• Specification : Detector type Vanadium Oxide Uncooled Focal Plane Arrays Response Waveband 8m to 14m FFC (Flat Field Correction) Auto, Manual, External Correction Highest Temperature Spot Tracking Yes Standby Mode Yes Refresh rate 50 Hz Resolution 160120 Recognition (Vehicles: 1.44.0m) - 153yd (Humans: 1.80.5m) - 50yd Detection (Vehicles: 1.44.0m) - 611yd (Humans: 1.80.5m) - 199yd Identification Range (Vehicles: 1.44.0m) - 76yd (Humans: 1.80.5m) - 25yd Lens system F1.1 NETD less than 35 mk (@25C), F#=1.1 Lens (focal length) 6.2 mm Field of view (H X) 15.61 11.74 (H V) Digital zoom 1, 2, 4 Display 720540, 0.2 inch, LCOS Storage Built-in memory module (8 GB) Record Video On-board video recording Capture Snapshot Yes Battery Type Built-in rechargeable Lithium battery Wi-Fi Yes Battery Operating Time More than 7 hours continuous running (with Wi-Fi hotspot function off) Battery Capacity Display Yes Power supply 5 VDC/2 A, 1.5 W, USB Type-C Interface Operating Temperature Range -20C to 55C (-4F to 131F) Weight 270 g (0.6 lb) Overall Dimensions 161 61 57 mm (6.3 2.4 2.2 in) Protection Level IP67
• Additional Included : USB CableWrist StrapPacking BoxOperators ManualLens Tissue
